PAFANA SMARTCUT TOOLS I.

new!

indexable inserts for turning:
grade of cemented carbide
P M K K(N) K(S) H
designation size thickness radius FP30S BP35W BP35W FP30S

XPNT 04 02 04 ER right
XPNT 04 02 04 EL left
XPNT 05 02 04 EN neutral
XPNT 080304EN FP30S
XPNT 06 02 04 EN neutral
XPNT 07 03 04 EN neutral
XPNT 08 03 04 EN neutral
XPNT 09 04 04 EN neutral
XPNT 10 04 04 EN neutral
XPNT 10 04 08 EN neutral
XPNT 13 05 04 EN neutral
XPNT 13 05 08 EN neutral
XPNT 17 06 08 EN neutral
XPNT
- to order - for settlement: term of realisation, serie available on stock

cutting data:
FP30S BP35W
Work piece material Type of treatment / alloy Vc Vc
( m/min. ) ( m/min. )
Non alloyed steel 50-230 70-250
Low alloyed steel 50-160 60-180
P steel High alloyed steel 50-150 50-160
Stainless steel 50-160 90-180
M Corrosion resistant steel Corrosion resistant steel 50-180 70-180

Grey cast iron 90-180 90-230
K Cast iron Spheroidal cast iron 90-180 110-230
Malleable cast iron 60-140 90-230

info.tech. ® 95
tech.info. 103-119
тех.инфо. XPNT 257
